OreikO HYCD412 Mobile scissor lift 4000kg / 120cm - 220V - CE

https://webshop.oreiko.com/web/image/product.template/3750/image_1920?unique=a1cf505

The OreikO HYCD412 occupies a unique position on the market of mobile scissor lifts due to its internal qualities peculiar to OreikO scissor lifts and its specifications: a maximum lifting height of 120cm, a lifting capacity of 4000kg and long platforms that make it easier to place larger vehicles on the bridge. Even the heaviest and lowest electric cars pose no problem, possibly in combination on the optional 100cm ramps.

Thanks to its features, this OreikO HYCD412 is the perfect transportable lift for the detailer, but also for the tyre dealer and the bodyshop/body shop.

    Because the hoses are extra long (3m) and a mobile kit is included as standard, this mobile scissor lift can be used very flexibly in the workshop. Of course, this lift does not need to be fixed to the floor, but is always possible via the holes provided on the floor plate.

      Thanks to the additional auxiliary frame (‘helper’) in the scissors, the lift has more power during the first 10cm. The advantages of the ‘helper’ function, being the extra subframe in the scissors (see photos):

        The total width of the lift without the foot guard is 183 cm, making it easier to drive a large (wide) car over it. The standard width of most lifts (side platforms) is only 176cm.

          Each HY3512 conforms to the current CE requirements (The CE test report can be viewed on special request):

          • dynamically tested (including safety operation) at 115% of maximum capacity
          • statically tested at 150% of maximum capacity (stability and deformation)

          Supplied/equipped as standard with:

          • lowering valve with emergency function
          • adjustable lifting speed
          • 2 sets of rubber support blocks of 3 and 6 cm
          • mobile set
          • power cable + plug
          • hydraulic oil
          • sound signal when lowering for the last 25 cm
          • foot protection on the side of the platforms
          • hydraulic pressure gauge

          Specifications:

          • Power supply : 220V, 1Ph - 13A
          • Motor : 2.2KW
          • Hydraulic pressure pump : max. 200 bar (adjustable)
          • Capacity : 4000kg
          • Minimum height : 11 cm
          • Maximum height : 120 cm
          • Ascent / descent time : 45s/30s (adjustable)
          • Platform width / length : 53cm/157cm
          • Space between the platforms : 77 cm

          Supplied in a wooden box on a pallet to avoid transport damage. 192x173x22cm - 575g / 93xx43x33cm - 59kg + oil

2,128.10 € 2128.1 EUR 2,128.10 €

2,128.10 €

Not Available For Sale

  • Color
  • Capacity
  • Brand
  • Packing dimensions

This combination does not exist.

OreikO Mobiele schaarhefbrug
Contact Us

Terms and Condition:
Price incl 21% VAT (BE) - Delivery / installation option For quotation or other models, please contact us

Lifts packed in wooden crates (no transport damage) and delivered with tailgate and pallet truck (except 2 pole lifts) Shipment of stock products: <24h after payment Manufacturer's warranty: 1 year

Share

Specifications

Hefbruggen
Color Red + black structure, Blue + anthracite structure, Grey
Capacity 4100 kg
Others
Brand OreikO
Packing dimensions 192x173x22 cm - 575 kg + 93x43x33 cm - 59kg
